|  EXPERIENCE CENTRE

Shanghai Haoyue Technology Co.,Ltd. is a high-tech enterprise integrating R&D, production and sales of electric furnaces.

Our material technology and thermal equipment experiment center has different types of thermal equipment, which can meet the test needs of customers for different process requirements, such as: vacuum hot pressing sintering multifunctional furnace, SPS spark plasma sintering system, etc., atmosphere sintering Furnace, hydrogen reduction furnace.

Series
 No. Operating Temperature
(℃)		 Heater Ultimate Vaccum (Pa) Chamber Size（mm） External Dimensions（mm） GW（Kg) Application
S2 SPS
System		 S2 2400 Pulse DC  6.7×10-3 80×300 1425×1550×1850 1500 SPS Sintering
S2D 2400 Pulse DC + Induction  6.7×10-3 80×300 1425×1550×1850 1500 Hybird Sintering
Series
 No. Operating Temperature
(℃)		 Heater Ultimate Vaccum (Pa) Chamber Size（mm） External Dimensions（mm） GW（Kg) Application
S2 SPS
System		 S2 2400 Pulse DC  6.7×10-3 80×300 1425×1550×1850 1500 SPS Sintering
S2D 2400 Pulse DC + Induction  6.7×10-3 80×300 1425×1550×1850 1500 Hybird Sintering
Series  No. Max.Temperature (℃) Chamber Size(mm) External dimensions （mm） GW （Kg) Heating Power (kW) Ultimate Vacuum (Pa) Application
V2 Vacuum Furnace
 V2GR20 2000 200*200*300 1425*1550*1850 1300 45 6.7*10-3 Sintering/Annealing/Degrease
V2GR23 2300 200*200*300 1425*1550*1850 1300 50 6.7*10-3 Braze/Annealing/Degassing
V2MO13 1300 200*200*300 1425*1550*1850 1300 40 6.7*10-3 Sintering/Annealing/degrease
V2MO16 1600 200*200*300 1425*1550*1850 1300 45 6.7*10-3 Sintering/Annealing/Degrease
V2W20 2000 200*200*300 1425*1550*1850 1300 45 6.7*10-3 Sintering/Annealing
V2W23 2300 200*200*300 1425*1550*1850 1300 50 6.7*10-3 Sintering/Annealing
V2CO20 2000 200*200 1425*1550*1850 1500 45 6.7*10-3 Sintering/Annealing
V2CO23 2300 200*200 1425*1550*1850 1500 50 6.7*10-3 Sintering/Annealing
V2MS17 1700 200*200*300 1425*1550*1850 1300 12 6.7*10-2 Sintering/Annealing/oxidize
Numbering
 Model Heater Structure Loading Chamber
Size（mm）		 Operating Temperature （℃）
 Heating Power （Kw) Ultimate Vaccum （Pa） Application
 Note
G2GR20/10  PVSgr 20/25-2000 GR Vertical Top Loading φ200×250 2000 50 10
 Gas pressure Sintering/Partial pressure/Degreasing Vertical, 10MPa Gas pressure furnace, heating rate 20°C/min,
G2GR20/1 PHSgr-20/20/30-2000 GR HorizontaI  Side Loading  200×200×300 2000 50 6.7*10-3 Gas pressure Sintering/Vacuum Sintering/Degreasing Horizontal, 1MPa Gas pressure, Vacuum Integrated Furnace , Heating rate 20°C/min,
G2GR20/P/1  PHSgr-20/20/30-2000 GR Horizontal Side Loading   200×200×300 2000 50 6.7*10-3 Gas pressure Sintering/Hot Pressing Sintering/Vacuum Sintering Horizontal, 1MPa Gas pressure, 300 KN Hot pressing Hydraulic pressure , Vacuum Integrated Furnace , Heating rate 20°C/min,

Tel: +86 21 5109 5281

Office Add: Building B2, 7301 Jiasong North Road, Jiading District, Shanghai,China



Factory Add: No.8 Hengshan Road, Development Zone Lu'an City, Anhui,China

Series No. Operating
temperature (℃)		 Chamber
Size （mm）		 External
dimensions （mm）		 Weight （Kg） Ultimate Vacuum
 (Pa)		 Application
D2 Diffusion Welding
 D2MO14 1400 200*200*300 1425*1550*1850
 1500 6.7*10-4 Diffusion welding/brazing/degassing
D2GR20 2000 200*200*300 1425*1550*1850
 1500 6.7*10-4 Diffusion welding/brazing/degassing
Series No. Operating
Temperature(℃)		 Heater Heating
Power(kW)		 Chamber
Size(mm)		 External
Dimentions
（mm）		 GW
（Kg）		 Operating
Temperature		 Tube Materials Application
R2 Rotary
Furnace
 R2 950 Resistance Wires 27 273*2400 1500×1280×860
 1000 950 SUS310S Calcination/Reduction
R2C 950
 Resistance Wires
 90 400*5500 3800×1390×1260 1500 950 SUS310S Calcination/Reduction

Custom solution



It is true that we cannot be experts in all professional fields, but years of professional experience ensure that we can provide solutions for complex processes.

For you, we will transform every new challenge into an economical and innovative solution. Our experts come from different fields and are your reliable and capable partners. They have years of experience in heat treatment in the industry, and these experience should be included in your solutions.





Focus on benefits



We have established our successful brand based on the quality and reliability of the equipment. We are customer-centric, combine theory and practice, and establish a complete sales network and convenient after-sales service. In our application of efficiency and economy to project work, design, materials and processes, as well as calculation and control technology, this is our strength.





Own heat treatment center for process development and testing



From laboratory test results to large-scale production, this is not a simple multiplication problem, because a suitable test-run equipment is relatively expensive and requires many parameters. In order to accurately obtain various parameters for production, 2019 We established a heat treatment center at the beginning of the year.

In this way, we can carry out small series production, process development, sampling, and if necessary, we can also find out how to seamlessly transition to large-scale product production. In this way, project operations can be carried out more efficiently and economically, even for demanding projects.

SPS/Hot press Q&A on sintering test



Q: Can insulation also be sintered?

A: There are many sintering examples such as oxide ceramics, carbide ceramics and nitride ceramics.



Q: What is the material of sintering element?

A: Graphite type (isotropic graphite) is generally used. In addition, C / C composites, superhard alloy and high temperature die steel are also used.



Q: Can porous bodies be sintered?

A: Although it depends on the particle size of the powder, the sintered body with a certain opening can be made. In addition, the closed pore structure can also be made by using the powder mixed with foaming agent and heat treatment after sintering.



Q: What is the furnace atmosphere in sintering?

A: Sintering is usually carried out in a vacuum atmosphere of about a few PA. Sintering in inert gas (argon or nitrogen) is also possible, but the gas pressure of sintering in inert gas atmosphere is below atmospheric pressure. In addition, in order to protect the sintering type, it is suggested that the sintering temperature should be below 400 ℃.



Q: What is the temperature measurement method in sintering?

A: When the sintering temperature is below 1000 ℃, a seamless thermocouple is used to measure the internal temperature of about 5mm from the periphery of the sintering type as the target of sintering temperature. When the sintering temperature exceeds 1000 ℃, infrared radiation thermometer is used to measure the temperature of the peripheral part of the sintering type from the vacuum chamber observation window.



Q: What are the goals for the progress and completion of sintering?

A: Generally, with the increase of sintering temperature, the sintered samples begin to shrink. Taking the shrinkage as displacement, the sintering end can be judged according to the sintering temperature and displacement state



Q: What is the application procedure for sintering test?

A: Please feel free to contact us on the "consultation" page or telephone number of our company or via email: sales@haoyue-group.com Contact us, please fill in the process information as much as possible in this "processing content book" and email to us.



Q: What is the cost of sintering test?

A: The rating varies depending on the sintering plant used, but the daily quota is the same. Depending on the size of the sinter and the sintering conditions, the quantity of production per day (about 8 hours) varies. In addition, the cost of sintering type and sintering accessory materials should be borne separately. First of all, please feel free to consult.



Q: Can site operation of sintering test be carried out?

A:Sintering test can be carried out.



Q: Can carry out a few ~ dozens of commission processing every month?

A:We will discuss according to the sintered products, please feel free to consult.



Q: What is the implementation period of sintering test?

A:It usually takes about 2-4 weeks if the sintering type (φ 5-30, 2-10 inch) can be used
