G series Vertical Gas Pressure Furnace
G series Vertical Gas Pressure Furnace
The furnace structure of the differential pressure impregnation equipment mainly consists of the furnace body, upper heating insulation system, lower heating in...
Key Features
Technical Highlights
1. The equipment is designed and manufactured according to the requirements of class 3 pressure vessel standards, and 16MnR or 304 furnace shell is adopted.
2. The door lock of the furnace is a bolt or tooth meshed quick release flange, which is easy to operate, safe and reliable.
3. The furnace cover is lifted and lowered by electro-hydraulic method, which is easy to operate and reduces labor intensity.
4. The insulation material in the furnace is carbon deposition composite hard felt, and the heating element is graphite imported from Germany.
Process Flow
Gas Pressure Process Overview
Gas pressure sintering follows vacuum or partial-pressure sintering with a high-pressure inert gas stage that closes residual porosity.
Selection guide
Confirm the process window before quotation.
For faster engineering review, prepare the core process boundaries before sending an inquiry.
Can the chamber be customized?
Yes. Chamber size, heating zone, fixture, pressure, and atmosphere configuration should be confirmed through technical review.
Is a process test recommended?
For new materials or demanding density targets, a sample process discussion helps reduce equipment selection risk.
What should be sent with an inquiry?
Material, target temperature, pressure or load, atmosphere, workpiece size, and expected capacity are the most useful inputs.
Official Specification Tables
Imported from Haoyue's official product data and reorganized for clearer technical review.
| No. | Model | Heater | Structure | Loading | Chamber Size (mm) | Gas Pressure (MPa) | Ultimate Vaccum (Pa) | Operating temperature (°C) |
|---|---|---|---|---|---|---|---|---|
| G3VGR20 | PVSgr-30/50-2000 | GR | Vertical | Bottom Loading | 300*500 | 10 | 10Pa | 2000 |
| G5VGR20 | PVSgr-50/80-2000 | GR | Vertical | Bottom Loading | 500*800 | 6/10 | 10Pa | 2000 |
| G7VGR20 | PVSgr-70/250-2000 | GR | Vertical | Top/Bottom Loading | 700*2500 | 6/10 | 10Pa | 2000 |
Typical Applications
